Stick Adapter M10062B Carrier
3D View
Section titled “3D View” Loading 3D model…
Description
Section titled “Description”The ‘Stick’ carrier board loses a couple of JST-GH connectors compared to the reference design carrier to make it as slim as possible but still keeps the 0.1″ headers for PWM outputs and has the most popular ports such as GPS, TELEM1, TELEM2, POWER and both CAN.
- Dimensions: 81.5 x 21.6 x 4.81 mm [3.21 in x 0.85 x 0.19 in]
- Distance between holes: 65.6mm x 15.6mm [2.58in x 0.61in]
- Hole size: 2.6mm [0.1 in]
- Weight: 4.7g [0.17 oz] / 6.54g without pins [0.23 oz]
